Cone Crusher Bowl Liner

Cone Crusher Bowl Liner

Cone Crusher Bowl Liner   What is the cone crusher bowl liner? A cone crusher bowl liner is a component that is fixed to the top of a cone crusher chamber and is designed to protect the chamber’s inner walls from the wear caused by the crushing process. The bowl liner is made of wear-resistant…

Details
Cone Crusher Bowl Assembly

Cone Crusher Bowl Assembly

Cone Crusher Bowl Assembly   What is cone crusher bowl assembly? The cone crusher bowl assembly covers the bowl, bowl liner, and hopper assemblies. The bowl which is threaded on its outside diameter is suspended on heavy-duty threads inside the adjustment ring. The bowl is adjustable, up or down, by turning the bowl counterclockwise or…

Details
Upper head bushing

Upper head bushing

Cone Crusher Upper Head Bushing   What is upper head bushing? The upper head bushing is a component of a cone crusher that is located on the top of the head assembly. It is typically made of bronze or other copper alloys and is designed to provide a smooth and consistent surface for the head…

Details
Lower head bushing

Lower head bushing

Lower Head Bushing   What is cone crusher lower head bushing? A cone crusher lower head bushing is a component that is located at the bottom of the main shaft assembly, which is attached to the eccentric drive rotating assembly. The purpose of the lower head bushing is to support the weight of the main…

Details
Cone Crusher Head Ball

Cone Crusher Head Ball

Cone Crusher Head Ball   What is cone crusher head ball? In a cone crusher, the head ball is the stationary upper part of the crusher mantle that sits on top of the main shaft. The head ball is usually made of hardened steel material and is typically bolted onto the top of the main…

Details
Replacing Cone Crusher Liners

How To Replacing Cone Crusher Liners?

How To Replacing Cone Crusher Liners?   What are cone crusher liners? The cone crusher liner is the main wearing part of the cone crusher during operation, also known as the cone crusher wear parts. It is made up of two bowl-shaped lining plates, the upper liner (which is called bowl liner or concave) and…

Details
Cone Crusher Head Assembly

Cone Crusher Head Assembly

Cone Crusher Head Assembly   What is cone crusher head assembly? A cone crusher head assembly is a component that is located at the top of a cone crusher and supports the mantle and the concaves. The head assembly is composed of several parts, including the main shaft, the head cap, the mantle, the thrust…

Details
Cone Crusher Socket Assembly

Cone Crusher Socket Assembly

Cone Crusher Socket Assembly The socket with the socket liner supports the head assembly and transmits the crushing force to the main frame. The socket is held rigidly to the main shaft by an interference fit and a series of capscrews installed around the perimeter of the socket. The socket liner which is dowelled to…

Details
Eccentric bushing

Eccentric bushing

Cone Crusher Eccentric Bushing The eccentric bushing is a component of a cone crusher that is located at the center of the main shaft. It is used to support the gyratory movement of the main shaft and also serves as a bearing. The eccentric bushing is made of bronze, which has good wear resistance and…

Details
Cone Crusher Eccentric Assembly

Cone Crusher Eccentric Assembly

Cone Crusher Eccentric Assembly Cone crusher eccentric assembly including the eccentric, eccentric bushing, gear, and counterweight. The eccentric which has an offset bore provides the means whereby the head follows an eccentric path during each cycle of rotation. An eccentric bushing locked into the eccentric bore provides the bearing surface for the main shaft. A…

Details
